2800 Quintuplex Plunger Pump
2800 Quintuplex large power plunger pump is applicable for Fracturing, Cementing, Sand proof, acidizing etc
The maximum pressure is up to 140MPa.
This pump is the largest power quintuplex plunger pump on the market.
Modern design,penetrating type connecting bolts make the connection more reliable;
Detachable packing box make the maintenance more convenient.
|
Max.Power Braking |
2,800HP (2,088KW) |
|
Max. Connecting rod Load |
229,305 lbf (1,020KN) |
|
Stoke |
8” (203.2mm) |
|
Driving Model |
Double cylinder oblige gear transmission |
|
Speed rations |
6.333:1 |
|
Dimension L×W×H mm |
91.38*91.42*47.44 in. (2,321*2,322*1,205mm) |
|
Weight |
20,900 lbs (9,500Kg) |
